Machine size and main parameters:
1： Equipment specifications
Equipment dimensions: L2200 * W3250 * H2380mm
Maximum board size: 730 * 630mm
Minimum board size: 300 * 300mm
Plate thickness: 0.1~6.0mm
Working height: 1100 ± 50mm
Production speed: 7PCS/min
Gas source: 0.6Mpa 200NL/min
Power supply: 380V/50Hz 2.5KW

2： Functional requirements
1. Reserve IO signals for interfacing with front and rear devices.
2. Equipped with a network communication module, capable of MES system communication.
3. It has four receiving stations and can be equipped with a code reader for board sorting.
4. The receiving platform has a lifting function, which can meet the loading and unloading needs of manual carts and AGV vehicles.
5. The suction mechanism is a Kawasaki 6-axis robotic arm with high stability and long service life.
